# BIGTREETECH TMC2209 V1.3 Stepper Motor Driver, UART/Step/DIR Mode, 5-28V Motor Voltage | Ultra-Silent Operation for 3D Printers **Brand:** BIGTREETECH **SKU:** rzj2944 **ASIN:** B07ZQ3C1XW **Canonical URL:** https://crowcrowcrow.com/p/bigtreetech-tmc2209-v1-3-stepper-motor-driver-uart-step-dir-mode/rzj2944 **Category:** electronics **Subcategory:** Categories **Availability:** in_stock **Price (INR, all-inclusive):** ₹4,169 **Discount:** 37% **Customer rating:** 4.60/5 from 514 ratings ## Description BIGTREETECH TMC2209 V1.3 stepper motor drivers offer ultra-silent operation for 3D printers, supporting UART and Step/DIR modes. With a 5.5-28V motor voltage and 2A continuous current, they prevent lost steps and jittering. Imported from authorized US retailers, all duties included. ## Highlights - Ultra-Silent StealthChop2 Operation — Experience significantly quieter 3D printing with StealthChop2 technology, reducing motor noise to a minimum for a more peaceful environment. Ideal for home or shared workspaces. - Precise Motor Control & Sensorless Homing — Achieve accurate movements with 256 microstep subdivision and UART/Step/DIR modes. Stallguard4 technology enables sensorless homing, eliminating the need for physical endstops and simplifying printer setup. - Wide Compatibility & Cost-Effective Upgrade — Directly replaces older drivers like TMC2100, A4988, DRV8825, and LV8729 on most 3D printer boards, including BTT Octopus, SKR, Manta, and MKS Gen L, offering a significant performance upgrade. - Reliable Performance & Durability — Designed to prevent lost steps and jittering with PWM chopper mode. Features an immersion gold PCB for better antioxidant properties and requires heat dissipation for sustained, reliable operation. ## Key features - Ultra-silent Stepper Motor Driver: BIGTREETECH tmc2209 v1.3 stepper motor driver adopts StealthChop2 silent motor operation technology is an ultra-silent motor driver IC for two-phase stepper motors. Continuous current up to 2.0A (peak 2.8A), voltage ranges from 4.75v to the maximun output of 28v. It can operate bipolar stepper motors from 1 to 1/256 step modes - BTT TMC2209 stepper motor driver support UART, STEP/ DIR Mode, except that you need to modify the firmware for the mode you use. for detailed tutorials, please refer to the BIGTREETECH GITHUB instructions - Sensorless Homing: BTT tmc2209 v1.3 stepper motor driver uses Stallguard4 locked motor technology to detect changes in motor current, providing an abnormal signal when the motor rotates abnormally. And use this measurement to detect the end of axis' stroke and produce 3D printers without limit switches - Widely Compatible: TMC 2209 stepper driver with most 3D printer motherboards on the market, such as btt octopus v1.1/octopus pro, skr v1.4 turbo/skr 3, Manta M4P/M5P/M8P, MKS Gen L... etc. It saves the expensive cost of redesign. It can perfectly replace the original non-silent TMC2100/A4988/DRV8825/LV8729 stepper driver and is the most cost-effective choice - Avoid losing steps and jittering: The motor controlled by the PWM chopper mode operated more smoothly and without jitter. It can effectively avoid problemsuch as running deviation losing step and fault caused by the overlode of the chip. Better printing effect - After-sales service: The manual and installation instructions have been uploaded to Github. If you have any problems during use, please tell us through Amazon ## Why choose this product - BIGTREETECH TMC2209 V1.3 drivers are built for superior performance in 3D printing. Their StealthChop2 technology drastically reduces motor noise, creating a quieter printing experience. With 256 microstep subdivision and support for UART/Step/DIR modes, they offer exceptional precision and smooth operation. Stallguard4 technology enables sensorless homing, simplifying setup and improving reliability by detecting motor stalls without physical end switches. The immersion gold PCB ensures better conductivity and longevity. These drivers are a direct, cost-effective upgrade for most 3D printer motherboards, enhancing print quality and reducing mechanical noise. — Engineered for Silent, Precise 3D Printing - These drivers are perfect for 3D printing enthusiasts and professionals who want to significantly reduce printer noise. They are ideal for users upgrading from older, noisier stepper drivers like A4988 or DRV8825. If you are experiencing lost steps, jittering, or simply desire a quieter printing environment, the TMC2209 is an excellent choice. However, users who require extremely high motor speeds beyond 2.8A peak current or are working with highly specialized, non-standard 3D printer control boards might need to verify compatibility or seek alternative solutions. — Ideal for Hobbyists & Professionals Seeking Quiet Upgrades ## How to use 1. Confirm your 3D printer motherboard supports TMC2209 drivers and the desired mode (UART or Step/DIR). Check for standard stepper driver sockets and consult your motherboard's documentation. — Verify Motherboard Compatibility 2. Gather necessary tools, including a heatsink and fan for heat dissipation. Ensure you have the correct firmware configured for your chosen mode (UART or Step/DIR) before proceeding. — Prepare for Installation 3. Carefully insert the TMC2209 driver into the motherboard socket, paying strict attention to the correct orientation to avoid damage. Attach the heatsink securely to the driver chip and connect the fan. — Install Driver and Heat Sink 4. Upload your modified firmware to the printer's control board. Power on the printer and test motor movement, sensorless homing, and overall print quality to ensure everything functions correctly. — Configure Firmware and Test ## Product details | Field | Value | |---|---| | Motor Voltage Range | 5.5V - 28V | | Logic Voltage Range | 3.3V - 5V | | Recommended Heat Dissipation | Heatsink + Fan required | | Installation Note | Ensure correct driver insertion direction to prevent damage. | | Firmware Modification | Required for selected mode (UART/Step/DIR) | | Brand | BIGTREETECH | | Model Name | TMC2209 V1.3 | | Style | 5*TMC2209 | | Color | Blue | | Material | PCB | | Motor Voltage | 5.5-28V | | Logic Voltage | 3.3-5V | | Current (Continuous) | 2A | | Current (Peak) | 2.8A | | RSense Resistance | 0.11 Ohm | | Microstep Subdivision | 256 | | Modes Supported | UART, Step/DIR | | Homing Technology | Stallguard4 (Sensorless) | | Package Quantity | 5 | | Item Package Weight | 17.9 g (0.018 kg) | | Country of Origin | Not stated by manufacturer — US retail version, sourced from authorized US retailers | ## Frequently asked questions ### How to ensure the BIGTREETECH TMC2209 V1.3 stepper motor driver fits my 3D printer? This TMC2209 driver is widely compatible with most 3D printer motherboards, including BTT Octopus, SKR, Manta, and MKS Gen L. Verify that your motherboard uses standard stepper driver sockets and supports UART or Step/DIR modes. Check your printer's firmware compatibility for these modes. ### What are the benefits of using TMC2209 drivers for my 3D printer? The TMC2209 drivers offer ultra-silent operation with StealthChop2 technology, significantly reducing printer noise. They provide precise motor control with 256 microstep subdivision, prevent lost steps and jittering for better print quality, and enable sensorless homing for simplified setup. ### How do I install the BIGTREETECH TMC2209 V1.3 stepper motor driver correctly? Ensure proper heat dissipation with a heatsink and fan. Crucially, pay close attention to the driver's direction when inserting it into the motherboard to prevent damage. Refer to BIGTREETECH's GitHub for detailed installation guides and firmware modification instructions. ### Can I use the TMC2209 driver for sensorless homing on my 3D printer? Yes, the TMC2209 V1.3 driver features Stallguard4 technology, which enables sensorless homing. This allows your 3D printer to detect axis endstops without needing physical limit switches by monitoring motor current changes. ### What is the difference between UART and Step/DIR modes on the TMC2209 driver? Step/DIR mode is the traditional method where each step pulse moves the motor. UART mode allows for more advanced configuration and control via a serial interface, often requiring firmware adjustments. Both modes offer precise motor control, but UART provides greater flexibility. ### How does the TMC2209 driver prevent lost steps and jittering? The driver uses PWM chopper mode and Stallguard4 technology to manage motor current effectively. This smooths motor operation, prevents excessive vibration, and detects abnormal motor behavior, thereby avoiding lost steps and ensuring more consistent print quality. ### How to buy an original BIGTREETECH TMC2209 V1.3 stepper motor driver in India? Purchase from authorized US retailers via crowcrowcrow.com for guaranteed authenticity. All customs duties and GST are included in the listed price, and products are shipped via ExpressBox tracked delivery to your Indian pincode. ## Compliance No product-specific compliance warnings identified. Standard imported-goods terms apply: customs duties & GST paid; for personal use in India; follow the manufacturer's usage instructions on the packaging. ## Images 1. https://images.crowcrowcrow.com/B07ZQ3C1XW-0.webp 2. https://images.crowcrowcrow.com/B07ZQ3C1XW-3.webp 3. https://images.crowcrowcrow.com/B07ZQ3C1XW-6.webp 4. https://images.crowcrowcrow.com/B07ZQ3C1XW-9.webp 5. https://images.crowcrowcrow.com/B07ZQ3C1XW-12.webp 6. https://images.crowcrowcrow.com/B07ZQ3C1XW-15.webp --- Source: https://crowcrowcrow.com/p/bigtreetech-tmc2209-v1-3-stepper-motor-driver-uart-step-dir-mode/rzj2944 Returns: 30 days, free, by mail. Shipping: Free across India, 7–13 business days. Prices are all-inclusive (duties + GST).
