Schneider Electric DPER02 Thermal Overload Relay 0.16-0.25A | Air Conditioner, HVAC, Compressor Protection

• This thermal overload relay can be used in a network frequency of 0-4000hz, the rated insulation is 600V cUL / 690V IEC, and tripping class 10, for protection of 3-phase motors for HVAC, elevators, pumps or compressors, and agriculture
• It features a compact and modular design, making it an ideal solution for space-constrained applications and can be quickly and easily configured to meet the needs of your specific application
• A reliable and cost-effective solution for protecting your motor against overloads, phase failures, and phase unbalances; durable, compact design to protect from dust and other environmental elements
• The thermal overload relay has phase-break protection, manual and automatic reset, temperature compensation, trip indication, test button, stop button
• Compatible with these Schneider Electric contactors DPE09G7, DPE09BL, DPE09U7, DPE09B7 and Schneider Electric’s Easy TeSys GP2E manual motor starter series; use with LAD7B106 Schneider Electric mounting adaptor

• Mount the relay — Secure the Schneider DPER02 on DIN rail or screw mount inside your control panel, ensuring proper orientation and connection points.
• Connect the wiring — Use screw clamp terminals to connect the relay's phase and load wires as per your motor's wiring diagram, ensuring correct polarity and tight connections.
• Set the thermal range — Adjust the thermal setting dial to match your motor's rated current (0.16-0.25A). Confirm settings are protected by the transparent cover.
• Test and commission — Use the test selector to simulate tripping, verify trip indication, then enable automatic or manual reset as needed for your application.

Typical situations where Schneider Electric DPER02 Thermal Overload Relay 0.16-0.25A | Air Conditioner helps — illustrative scenarios, not customer reviews.
